Hotmelt coating and laminating systems
for glass fiber film in a modular construction for hotmelt spray application using a multi-module applicator. The modules can be activated and de-activated in sections to generate different widths and images. Optional: route control. Material width 1250mm, winder in a cantilever design (winding shafts mounted on one side).
Complex PUR coating system
for coating a textile foam composite with a width of 2300 mm using a wide slot nozzle. With a double unwinding station, cooling, material storage and rewinder with cutting device.
Coating stand with nozzle swapping system
Complex coating module for swapping adhesives and high adhesive throughput for integration in coating lines. The swapping system for two integrated wide-slot nozzles permits changeovers to different adhesive systems, e.g. PSA to butyl, in less than 30 minutes. Productivity can be maximized by simply integrating additional drum melters (up to 12).
consisting of two coating and two laminating stations for the production of a trilaminate with a width of 1600 mm at production speeds of up to 100 m/min. The uniform and low-maintenance spray application with 8 angle heads (e.g. PUR or PSA possible) permits flexible width changes by activating and deactivating the applicators. Application weights of less than 5 g/m² can be achieved with the spray system.
Production of a trilaminate by spray application
Single-sided coating stand for producing butyl sealing tapes
Coating width adjustable 50 - 400 mm; up to 2000 g/m² butyl application.
Can be extended with the addition of a second width-adjustable nozzle to produce a multi-layer laminate. Compact design with direct cooling, second unwinding and edge-controlled feeding of a release liner.
Combi media line
for producing filter materials with a width of up to 1600 mm at production speeds of up to 25 m/min. With two stations consisting of PUR spray application and subsequent granulate scattering. Also suitable for multiple runs for different product variants.
Multi-axis coating gantry
Multi-axis coating gantry for coating special hoses. A fabric is unwound, coated inline with PUR hotmelt and positioned directly on a rotating hose core by the movable gantry and wound around it traversely.
SM Coating
Your specialist for complex hot-melt coating systems
We offer ultra-modern, efficient coating systems for dispensing thermoplastic and reactive hot-melt adhesives. We are a medium-sized specialist engineering company with an international presence that offers made-to-order, high-quality coating systems customised to your needs.
SM Coating’s total service package comprises all the services you need from a single source – from planning and design to construction and assembly to service and maintenance.
Our hot-melt coating systems are used for the targeted coating of surfaces in a wide range of industries. They are suitable for dispensing.
Areas of application include the textile, foil and film, and furniture industries (e.g. for manufacturing coated textiles, labels and decorative films), and the manufacture of building materials, adhesive tapes, sealing tapes and paper. In addition to this, we manufacture coating systems for the automotive supplier industry.
Image film of the parent company SM Klebetechnik
Mit dem Laden des Videos akzeptieren Sie die Datenschutzerklärung von YouTube.
Mehr erfahren
PUR coating system for sheets of TPO or PVC interior trim
Hot-melt coating unit that accepts a wide slit nozzle
In-line coating system from the roll to the cutter
Coating and lamination of textiles
Valuable Insights for Better Understanding
SM Coating completes laboratory coating line for research project
Compact and expandable system for product development and analysis – potential use in many industries As part of an international university project, the Heinsberg-based specialist plant manufacturer, SM Coating, has designed and completed a new, [...]
